Product Overview
Designed for precision and adaptability in modern furniture assembly, these matte gray die-cast zinc square leveling feet deliver seamless floor compensation on uneven surfaces—ideal for cabinets, workbenches, retail displays, and modular office systems. Their square base ensures stable load distribution across all four corners, while the integrated M10 threaded insert allows direct, tool-free rod attachment without secondary adapters. Unlike round counterparts, the square leveling feet provide superior lateral resistance against twisting or slippage during installation or daily use. Crafted from high-density die-cast zinc alloy with a durable matte gray finish, they resist corrosion, chipping, and visual fatigue—blending discreetly with industrial, minimalist, and commercial interiors. U01SFJ027 is engineered not just to level, but to anchor confidence in every installation.
Key Features
- Square mounting plate (50 mm × 50 mm) with precisely spaced 4-hole pattern for universal cabinet/base compatibility
- Internal M10 threaded insert—no loose nuts or external threading required; accepts standard M10 leveling rods
- Die-cast zinc alloy construction ensures rigidity, vibration damping, and long-term dimensional stability
- Matte gray electrostatic powder coating resists scuffs, fingerprints, and environmental wear
- Adjustable height range of 60–100 mm accommodates diverse floor tolerances and leg configurations
Specifications
| Model / Part Number | U01SFJ027 |
|---|---|
| Material | Aluminium |
| Dimensions | Ø50mm, H60-100mm |
| Application | Sofa/soft seating/modular lounge/custom furniture |
Applications
These square leveling feet excel where stability, repeatability, and aesthetic cohesion matter: built-in kitchen islands requiring flush-floor alignment; freestanding medical carts needing anti-wobble assurance; exhibition stands exposed to foot traffic; and custom shelving systems installed over tile, concrete, or subfloor inconsistencies. Their square profile integrates cleanly with CNC-cut panels and metal frames—making them a preferred choice for OEM furniture manufacturers and contract installers who prioritize both functional tolerance and design continuity.
Why Choose UKLinkHardware
We manufacture square leveling feet to ISO 9001-certified standards, with 100% dimensional inspection per batch. Lead time stays under 12 days for standard orders, and we support full OEM customization—from bespoke thread specs (M10/M12) to branded packaging and laser-etched part IDs. Every U01SFJ027 unit undergoes salt-spray testing (≥72 hrs) and torque validation to guarantee insert integrity across 10,000+ adjustment cycles.
FAQ
Can these square leveling feet be used with M12 rods?
No—U01SFJ027 features a fixed M10 internal insert. For M12 compatibility, specify model U01SFJ028 at order.
Do I need additional hardware to mount them?
No. The 4 pre-drilled holes align with industry-standard 5 mm screw spacing; mounting screws are included in bulk orders upon request.
Will the matte gray finish match brushed aluminum furniture frames?
Yes—the low-gloss zinc finish is spectrally tuned to harmonize with anodized 6063-T5 and powder-coated aluminum extrusions without visible contrast.
Are they suitable for outdoor-rated furniture?
Not recommended for prolonged direct exposure—they’re rated for indoor/commercial environments with occasional humidity (e.g., basements, garages), but lack UV-stabilized coatings.
